# Conical Springs

Conical springs are a type of compression spring with a wider diameter at the base and a smaller diameter at the top.

This design has the benefit of allowing a reduced solid height as the smaller coils will fit partially, or sometimes fully, inside the larger coils below.

Watch the video to find out more.

# Tension Spring End Types

The 5 commonly used end types are:

1. Machine Loop
2. Crossover Loop
3. Side Loop
4. Extended Ends
5. Coned Ends

Watch the video to find out more.

# Common Mistakes in Torsion Spring Design & Use

There are 4 key Torsion Spring design flaws that can affect the performance of a torsion spring.

1. Incorrect direction of operation
2. Inside diameter too small
3. Body length too large
4. Overstressed

Watch the video to find out more.

# Torsion Spring Leg Types

Torsion spring legs come in many different forms, with almost infinite possible variations.

There are four main torsion spring leg types, determined by the way the legs leave the spring body

• Tangential
• Axial

Watch the video to find out more.

# Measuring a Tension Spring using a Digital Vernier Caliper

How to measure a tension spring using a digital vernier caliper.

Watch the video to find out more.

# Measuring a Compression Spring using a Digital Vernier Caliper

How to measure a compression spring using a digital vernier caliper.

Watch the video to find out more.

# Initial Tension

The initial tension is released, when a tension spring is extended to a certain point, where gaps appear between the coils.

Watch the video to find out more.

# Tension Spring Rate

The rate is the strength of a spring as defined by Hooke’s law.

Hooke’s Law states that the force needed to extend a spring is directly proportional to the distance you stretch it. Hooke’s Law can be represented as F = ks.

‘F’ is the spring’s restoring force

‘k’ is the spring constant

‘s’ is the deflection (extension)

Watch the video to find out more.

# Counting Coils on a Tension Spring

Counting coils on a tension spring is the same as counting coils on a compression spring.

The type of ends on a spring will make no difference to the number of coils.

Watch the video to find out more.

# Loads at Length for a Tension Spring

How spring loads work within a tension spring. If too much weight is applied to the spring it will no longer contract, therefore breaking the spring.

Watch the video to find out more.

# Measuring the Length of a Tension Spring

How to measure the length of a tension spring.

Watch the video to find out more.

# Diameters of a Tension Spring

How to measure the diameters of a tension spring.

Watch the video to find out more.

# Spring Tolerances

Tolerances refer to the acceptable variation that will allow a spring to function.

Watch the video to find out more.

# Compression Spring Rate

This video shows you how to calculate the rate of a compression spring defined by Hooke’s Law.

Watch the video to find out more.

# Loads at Length for a Compression Spring

The video shows you how spring loads work and how it is derived from spring rate.

Watch the video to find out more.

# Outside Diameter Expansion of a Compression Spring

As a spring is compressed the pitch of the spring is reduces, expanding the outside diameter.

Watch the video to find out more.

# End Types of a Compression Spring

There are three different kinds of end types of a compression spring.

Watch the video to find out more.

# Active & Dead Coils of a Compression Spring

Compression springs can consist of active coils and dead (inactive) coils.

Watch the video to find out more.

# Spring Winding Direction

This video in our Springtelligence video series will show you the winding direction of a spring.

If two compression springs have to operate together (one inside the other) it is important for them to be wound in opposite directions, this will prevent the coilsÂ from getting entangled.

Watch the video to find out more.

# Gap & Pitch of a Compression Spring

This video in our Springtelligence video series will show you the gap between two adjacent coils of a compression spring and the simplest method of measuring the pitch on a compression spring.

Watch the video to find out more.

# Diameters of a Compression Spring

The third video in our new Springtelligence video series will show you the Wire Diameter (d), Outside Diameter (OD), Inside Diameter (ID), and Mean Diameter (D) of a compression spring.

Watch the video to find out how to identify and then measure the Wire Diameter (d), Outside Diameter (OD), Inside Diameter (ID), and Mean Diameter (D) of a compression spring.

# Measuring Compression Spring Lengths

When specifying springs you must know your springâ€™s dimensions. There are millions of possibilities when it comes to spring design, so just knowing theÂ working loads or the spring rateÂ will not be enough as the spring can be any size in diameter or length.

Watch the video to find out how to measure compression spring lengths.

# How To Count Coils

Counting the coils of a spring is one of the most frequently misinterpreted concepts of spring manufacturing. Failure to count and specify coils correctly can result in errors in specification drawings which can then carry through to the final production of the spring.

Watch the video to find out how to count coils correctly.
