Common Mistakes in Torsion Spring Design – Video

Categories: Company News, News, Springs, Springtelligence, Videos|278 words|1.4 min read|By |Published On: April 6th, 2022|

Our brand-new Springtelligence video looks at the common mistakes made when designing a torsion spring. The four main spring design flaws which we look at and demonstrate in this video are:

– Incorrect direction of operation

– Inside diameter too small

– Body length too large

– Overstressing

It is also important to consider:

– The size of the mandrel over which the spring operates. The inside diameter of a torsion spring reduces during deflection; therefore, if insufficient space is allowed the spring may bind on the mandrel and break/deform.

– The size of the hole within which the spring operates. The outside diameter of a torsion spring expands during deflection as more wire feeds into the body of the spring during deflection; therefore, if there is insufficient space, the spring may bind within the space and break/deform.

– The lateral space available. As a torsion spring deflects, it increases in length and may fail if this growth cannot be accommodated in the application.

– The torques/forces and rotation required.

– The intended environment. This will affect the suitable material and and finish requirement (i.e. for corrosion protection).

– The maximum working deflection required.

– The frequency of operation.

– How and where the spring fits. This will determine type of ends required.



Click the link to find out more and visit our YouTube page for further videos explaining all things springs:

Common Mistakes in Torsion Spring Design & Use – YouTube
